SLA 3D Printed Brick Houses with Arched Doorway Resin Scale Model

SLA 3D Printed Brick Houses with Arched Doorway Resin Scale Model

facfox-case-study
Process 3D Print, Support Removal, Post Curing, Primer Coating, Paint, Glueing
Material Resin
Quantity 1 pcs
Price Range $100-1,000
Lead Time 7 workdays

Gallery

About Project

Discover the charm of classic architecture with FacFox’s latest creation: the SLA 3D Printed Brick House. This exquisite scale model showcases a stunning blue-painted brick facade, complemented by a crisp white flat roof, ground sill, and footsteps that invite you into its cozy embrace.

The design features two large arched windows adorned with intricate grid-like patterns, set above elegant grey brick sills that add a touch of sophistication. The centerpiece is the grey arched doorway, thoughtfully assembled with a hinge, allowing the door to swing open and welcome visitors into the warmth of the home.

Adjacent to the main structure is a versatile overground garage, which doubles as a quaint room, perfect for creative space or storage. Inside, you’ll find charming red chairs, stools, and bed models, each crafted with precision and care.

FacFox’s manufacturing services bring this architectural wonder to life, offering a glimpse into the potential of 3D printing in the architectural industry. Whether for professional architects seeking a detailed representation of their designs or hobbyists looking for a unique addition to their collection, this resin scale model is a testament to the possibilities that lie within precision 3D printing.

Embrace innovation and tradition with FacFox – where your architectural visions become tangible realities.

Solution

  • Step 1: Design Phase. The model was designed using CAD software, where meticulous attention to detail was ensured for the brick house’s features, including the arched windows, doorway, and interior furnishings.
  • Step 2: Preparation. The design file was then converted into an STL format, which was subsequently uploaded to the SLA 3D printer’s software.
  • Step 3: Support Structures. Supports were generated and attached to the model where necessary, ensuring stability and maintaining the integrity of overhanging features and fine details.
  • Step 4: Printing Process. The build platform was lowered into a tank filled with liquid resin. A UV laser was employed to cure the resin, solidifying the first layer of the model.
  • Step 5: Layer Formation. The build platform was incrementally raised, and the laser continued to cure the resin layer by layer, allowing the brick house model to take shape.
  • Step 6: Post-Processing. Once the printing was completed, the model was carefully removed from the build platform. The supports were then removed, and the model was washed in isopropyl alcohol to eliminate any uncured resin.
  • Step 7: Curing. The model was placed in a UV curing chamber to further harden the resin, ensuring durability and the correct final properties of the material.
  • Step 8: Assembly. The arched door, which was printed separately with a hinge, was attached to the main structure, allowing it to open and close.
  • Step 9: Painting. The brick house model was hand-painted in blue, with the roof, ground sill, footsteps, and window sills painted white, and the door and window sills in grey, as per the design specifications.
  • Step 10: Finishing Touches. Finally, miniature furniture models, including red chairs, stools, and a bed, were placed inside the garage to complete the scene.
