MJF 3D Printed Full-color HP Nylon RPG Minis Custom Statue for Board Game

MJF 3D Printed Full-color HP Nylon RPG Minis Custom Statue for Board Game

facfox-case-study
Process 3D Print, Polish
Material Plastic
Quantity 1 pcs
Price Range $100-1,000
Lead Time 3 workdays

Gallery

About Project

Check out this amazing full-color nylon RPG miniature crafted with the help of MJF 3D printing technology!

This miniature is made from a unique material called HP 3D High Reusability CB PA12 which offers vibrant colors, extraordinary surface effects and intricate details.

The material is more expensive than other colorful 3D printing materials, but is worth the added cost as it brings a level of sophistication to your gaming experience.

With its intricate colors and details, this miniature will take your board gaming to the next level!

Solution

  • Step 1: The mini was designed and colors were assigned to different parts of the model. Any color from the CMYK could be used.
  • Step 2: The model was then exported as a 3MF file, which was a format that supports full-color information.
  • Step 3: Then, the 3MF file was uploaded to the HP SmartStream 3D Build Manager software, which prepared your model for printing by slicing it into thin layers and optimizing its orientation and placement on the build platform.
  • Step 4: The nylon powder and the color agents were loaded into the HP Jet Fusion 300/500 series printer. The printer heated up the powder bed to just below its melting point and then deposited a thin layer of powder on top of it.
  • Step 5: Next, the printer used an inkjet array to selectively apply color agents and a fusing agent onto the powder layer according to the 3D model. The color agents changed the color of the nylon powder while the fusing agent helped bond it together.
  • Step 6: The printer used an infrared lamp to fuse the powder layer into a solid part. The lamp would only heat up where the fusing agent was applied, leaving the rest of the powder unaltered.
  • Step 7: Finally, after repeating these steps for each layer of the 3D model, the finished statue was removed from the printer and any excess powder was clean off. You could also post-process your part by sanding or polishing it if needed.
