CNC Machining Stainless Steel Koenigsegg Automobile Catalytic Converter Prototype

CNC Machining Stainless Steel Koenigsegg Automobile Catalytic Converter Prototype

facfox-case-study
Process CNC
Material Metal
Quantity 1 pcs
Price Range $1-100
Lead Time 2 workdays

Gallery

About Project

These catalytic converter prototypes are customed for Koenigsegg Automotive AB. As for incorporating the text characters into the surface, we require your attention and advice on raised texts, a bold sans-serif font of 20 points or more, and stay away from the tops of tall features.

Solution

  • Step 1: The CAD model was examined and transformed into a CNC-compatible format with the software AutoCAD.
  • Step 2: A most suitable type of CNC machine was chosen according to the complexity of the product design and the cost of the workpiece.
  • Step 3: Certain operations were configured and the G-codes were input on the machine. The workpiece was mounted on the machine as well.
  • Step 4: The workpiece got shaped and the holes were drilled automatically. It would be inspected during and after the machining process for quality assurance.
