SLA 3D Printed Resin Binary Code Face Artwork Prototype

SLA 3D Printed Resin Binary Code Face Artwork Prototype

facfox-case-study
Process 3D Print, Support Removal, Post Curing, Polish
Material Resin
Quantity 1 pcs
Price Range $1-100
Lead Time 5 workdays

Gallery

About Project

The binary code face is common in some sci-fi movies, and the printed model is still striking. This large-scale artwork is beyond our 3D printer's build volume, so it has to be split and then glued together.

Solution

  • Step 1: The client split the model into different parts, and export the STL file for printing. Our engineers help him examine the model.
  • Step 2: We arrange the parts in software and add necessary supports. Then 3D print them with SLA Generic Resin. The layer thickness we set is 0.05mm and we control the tolerance within ±0.1 mm.
  • Step 3: When printing is completed, rinse the models with IPA and post-cure them with UV. Cut off all the supports, then polish with sandpaper.
  • Step 4: Inspect the prints randomly with calipers and magnifiers to ensure all the prints have a correct dimension and a good surface effect. Finally, glue them together into one piece.
