SLA 3D Printed Embossing Roller Gears Of Mask Making Machine For Prototyping

SLA 3D Printed Embossing Roller Gears Of Mask Making Machine For Prototyping

facfox-case-study
Process 3D Print
Material Resin
Quantity 4 pcs
Price Range $100-1,000
Lead Time 4 workdays

Gallery

About Project

The embossing roller gears are important components of the mask making machine, and a company found us to make some prototypes for verification. We use an SLA 3D printer to produce 4 pieces of embossing gears in resin. The prototype precisely reflects all the tiny patterns. After passing the verification process, the end-usable gears are CNC machined and assembled on the mask making machine.

Solution

  • Step 1: 3D modeling based on the design print offered by our customer.
  • Step 2: SLA 3D printing with SLA Generic Resin.
  • Step 3: Post-processing.
  • Step 4: Model verification.
  • Step 5: CNC machined the embossing roller gears.
