SLA 3D Printed Curved Enclosure With Space Grid Structure

SLA 3D Printed Curved Enclosure With Space Grid Structure

facfox-case-study
Process 3D Print, Support Removal, Post Curing, Polish
Material Resin
Quantity 1 pcs
Price Range $100-1,000
Lead Time 2 workdays

Gallery

About Project

In architecture and structural engineering, a space frame or space structure (3D truss) is a rigid, lightweight, truss-like structure constructed from interlocking struts in a geometric pattern. Space frames can be used to span large areas with few interior supports. The biggest challenge in 3D printing space structure lies in support removal. Sometimes it requires more materials for the supports than the part itself.

Solution

  • Step 1: Arrange the placement properly and add support structure to the curve part to save the materials for supports.
  • Step 2: 3D print the part with our industrial SLA 3D printer. SLA ABS-like Resin is used for its outstanding machinability.
  • Step 3: Cut off the supports, rinse with IPA, then post-cure with UV. Patience is needed for support removal in case it may break.
