SLA 3D Printed Resin Bone Models as Medical Teaching Aids

SLA 3D Printed Resin Bone Models as Medical Teaching Aids

facfox-case-study
Process 3D Print, Support Removal, Post Curing, Polish
Material Resin
Quantity 42 pcs
Price Range $1-100
Lead Time 3 workdays

Gallery

About Project

Training doctors and surgeons on proper techniques can decrease recovery time and increase patient quality of life is critical. 3D printed bone models could not only demonstrate our surgical device but actually teach surgeons.

Solution

  • Step 1: Arrange the placement of all the bone models in the software and add the supporting structures. Export the STL files into the SLA 3D printer.
  • Step 2: 3D print the teeth model with SLA Generic Resin(Grey). The material offers optional layer heights of 0.05 and 0.1 mm, and the tolerance is ±0.2%. It’s suitable for fine-detail models with smooth surfaces and complex designs with intricate details.
  • Step 3: Cut off the supports, rinse with IPA, then sand and polish the models to remove bumps.
